Steel Door Dublin Steel Doors galway Fire roller shutter doors steel roller shutter door

Steel Doors:   Fire Doors.Fire insulated Doors.Fire escape Exit Doors.Security Doors.Personnel Door.Shed Door.Metal Door.Fire resistant Doors.
Shutters:   Steel Roller Shutter Doors.Fire Shutters.Security Shutters.PVC Shutters.Fire insulated shutters.Fire resistant shutters.Alu Roller shutters.
Other doors:   Fire Curtains doors.Section Doors.High speed dooors.Insulated section doors.garage doors,ESB doors.Galvanized doors.

AE Doors (Ireland) -   a member of Everest Products Group in steel door solutions.
Manufacturer -   Steel Doors & Roller Shutters Doors.
Leading distributor -   over 1000 standard size steel door sets in stock.
Location -   Production facility located in Dublin.
Delivery -   Over night nationwide delivery to any city & town all over Ireland.
Project techical sales team -   specialist on all projects in steel doors and roller shutters solutions.
Supply with installation -   Private & Commerical : Door Traders, Builders,  Contractors,  Architects & Construction developement..

Door and Frame Specification:

* Door feature:
-- Fire doors tested with BS 476 P20&P22 and CE EN 1634-1:2000 fire resistant standard.
-- All doors can be both exterior or interior used.
-- Frame fixed by adjustable fitting screws.
-- Sealing system available on all 4 side around to reduce noise,smoke,dust etc.
-- Security hook sash lock & soild stainless steel security handle and escutcheon are available as standard.
-- Double door build-in with high security flush bolt and double astragal as standard.


* Door feature:
All doors can be both exterior or interior used
Fire doors tested compliant BS 476 P22 Section 8 fire resistant standard
Fire door rating:0-4 hours
Door leaf thickness:50 mm
Door frame thickness:100 mm
Door leaf skin steel:1.0-1.6 mm Galvanized steel reinforced.
Door frame steel:1.6 -2.0 mm Galvanized steel reinforced.
Infill: Stiffened, insulated and sound deadened honeycomb core with fireproof glue pre-expanded and laminated.
Reinforced: Compliant with the position for  ironmongery reinforcements.lock, panic bar, door closer etc.
Frame fixed by adjustable fitting screws.
Security Performance : 25 mm security astragal covered on all doors

* Mortice Lock set option:
Heavy duty euro sash lock with latch and hook dead bolt.
Heavy duty solid stainless steel security lever handles with solid stainless steel security escutcheons.
Euro cylinder with thumb turn.or double euro cylinder on both side.Master key system is available.

* Fire escape exit Panic device option:
For fire escape door can be Fitted with panic latch or panic bolt by fire regulation requirement.
Extra reinforced plate: on the position for lock, panic bar, door closer etc.
Threshold: 12 - 17 mm height made by stainless steel or galvanized finished. or no threshold for interior use.

* Surface finish:

Finish: Powder coated.
Standard colour: RAL 7016.
Other colour: available for extra option.

* Standard Hardwares:

Door Hinges: Heavy duty stainless steel with anti-theft dog bolt.
3 or 4 hinges on each door leaf.
Receiver:Noise reduced & adjustable lock receiver.

* Option hardwares:

-- Key & Handle option:
Heavy duty oval type sash lock with dead bolt
Heavy duty stainless steel lever handles with solid stainless steel rose.
Heavy duty Oval cylinder with stainless steel thumb turn & solid escutcheon
blank key is available

-- Fire escape exit Panic device option:
Heavy duty panic device work with the lock case suit variable option faction,
the faction such as:
panic latch with fire proof dead lock,
panic latch with fire proof outside access key system,
panic latch automatic lockable
panic latch manually free lock the fire door etc.
For double frie exit door can be Fitted with panic latch and panic bolt for fire exit.


* Roller Shutters Doors:

Industry Shutters / Retail Shutters / Commercial Shutters / Fire Shutters / Fire Insulated Shutters / PVC Shurrers/ Aluminum Roller Shutter Doors /Fire Resistant Shutters.

Solid Roller Shutter Details

Shutters lath option:
75mm curved solid steel lath
50mm flat solid steel Lath
50mm flat solid aluminium Lath.
Finsish option:
Galvanised / PVC / Powder coated / Mill aluminium
Steel lath thickness option:
From 0.7mm to 1.2mm
Operation option:
Electrical: Tubular motor or Industry motor, all motor with manual release in case of an absence of power.
Manual: Chain release only (size not exceed 6 Sqr Metres)
Electrical option:
Single phase or 3 phases
Control option:
Key swith / Stop button box / Remote control

Perforated Shutters lath option:
75mm curved perforated steel lath
75mm curved Punched steel lath
50mm flat Punched steel Lath
50mm flat Punched aluminium Lath.
Finsish option:
Galvanised / PVC / Powder coated / Mill aluminium
Steel lath thickness option:
From 0.7mm to 1.2mm
Operation option:
Electrical: Tubular motor or Industry motor, all motor with manual release in case of an absence of power.
Manual: Chain release only (size not exceed 6 Sqr Metres)
Electrical option:
Single phase or 3 phases
Control option:
Key swith / Stop button box / Remote control

Fire Shutter Details
The fire shutters are designed to meet BS476:P22 / CE EN1634-1:2000 standard specifications.
Fire rating:
0-4 hours
Shutters lath option:
75mm curved solid steel lath
50mm flat solid steel Lath
Finsish option:
Galvanised / Powder coated
Steel lath thickness option:
From 0.7mm to 1.2mm
Operation option:
Electrical: Tubular motor or Industry motor with fire alarm control panel, all motor with manual release in case of an absence of power.
Electrical option:
Single phase or 3 phases
Control option:
Key swith / Stop button box / Fire alarm panel

Customer Service:01-2548877.  Email:  info@aedoors.ie                Project Techical Sales:  086-3638888.  Email: sales@aedoors.ie
